MAIN HIGHLIGHTS:
- -Highly Efficient Cold Rooms & Storage that is easy to operate and better in performance.
- -Available in standard sizes and customized Specifications to fulfill customer needs.
- -Temperature Range from +15 to -40
COLD ROOM TECH SPECS. & RANGE :
| Thickness | 60, 80,100, 125 & 150 mm |
| Surface | Gl Pre-Painted Sheet, S.S. Sheet (Grade Material: 304/316 & Surface finish 2B & Mate), Gl Plain Sheet, Plain Galvanized Iron. (Inside & Outside different metal can be placed as per your requirement) |
| Floor |
|
| Door |
|
| Room Size |
|
SPECS. FOR COLOR COATING
- A. RAL No. : 9002/9003 or it's nearest
- B. Indian Standard code Colour Coating IS 14246 Galvanizing: IS 277 Base Metal: IS 513
- C. Organic Coating: Type RMP (Polyester)
- D. Zinc Coating: 120 GSM
- E. Top Primer (Thickness in micron 'μ') : 5 +/- 1 μ
- F. Top Coat (Thickness in micron 'μ') : 20 +/- 1 μ
- G. Back Primer (Thickness in micron 'μ'): 4 +/- 1 μ
- H. Back Coat (Thickness in micron 'μ'): 4 +/- 1 μ
- I. Guard Film (Thickness in micron 'μ'): 40 +/- 3 μ
- J. Salt Spray Test /Humidity Test: 750 hrs. /1000 hrs.
